Switching times t in ms (installation position: solenoid horizontal) |
|||||||||
|
Pressure p |
Flow qV |
tON without tank pressure |
tOFF |
||||||
|
C |
U |
Y |
D |
C |
U |
Y |
D |
||
|
70 bar |
4 l/min |
140 |
160 |
150 |
170 |
110 |
100 |
120 |
110 |
|
140 bar |
4 l/min |
150 |
165 |
160 |
175 |
120 |
110 |
130 |
120 |
|
280 bar |
4 l/min |
170 |
170 |
180 |
180 |
125 |
135 |
135 |
145 |
|
320 bar |
4 l/min |
175 |
170 |
185 |
180 |
130 |
140 |
140 |
150 |
|
420 bar |
4 l/min |
185 |
170 |
195 |
180 |
135 |
145 |
145 |
155 |
|
Notice: The switching times were determined at a hydraulic fluid temperature of 40 °C and 46 mm2/s. Deviating hydraulic fluid temperatures can result in different switching times. Switching times change dependent on operating time and application conditions. |
|||||||||
