Size |
23 | 32 | 45 | 63 | 80 | 107 | |||
|
Displacement |
Vg |
cm³ |
22.9 | 32 | 45.6 | 63 | 80.4 | 106.7 | |
|
Nominal pressure |
pnom |
bar |
350 | 350 | 350 | 350 | 350 | 350 | |
|
Maximum pressure |
pmax |
bar |
400 | 400 | 400 | 400 | 400 | 400 | |
|
Maximum speed |
nnom 1) |
rpm |
3050 | 2750 | 2650 | 2200 | 2150 | 2000 | |
|
nmax 2) |
rpm |
4300 | 3900 | 3800 | 3200 | 3100 | 2800 | ||
|
Flow |
at nnom |
qV |
l/min |
70 | 88 | 121 | 139 | 173 | 213 |
|
Power |
at nnomand pnom |
P |
kW |
41 | 51 | 71 | 81 | 101 | 124 |
|
Torque |
at pnom |
M |
Nm |
127 | 178 | 254 | 351 | 448 | 594 |
|
Rotary stiffness |
c |
kNm/rad |
2.56 | 3.12 | 4.18 | 6.25 | 8.73 | 11.2 | |
|
Moment of inertia for rotary group |
JTW |
kg·m² |
0.0012 | 0.0012 | 0.003 | 0.0042 | 0.0072 | 0.0116 | |
|
Maximum angular acceleration |
ɑ |
rad/s² |
6500 | 6500 | 14600 | 7500 | 6000 | 4500 | |
|
Case volume |
V |
l |
0.25 | 0.29 | 0.4 | 0.5 | 0.6 | 0.75 | |
|
Mass moment |
MG |
Nm |
4.7 | 4.7 | 8.6 | 9.9 | 15.3 | 20 | |
|
Weight (approx.) |
m |
kg |
5.9 | 5.9 | 8.4 | 9.3 | 12.3 | 15 | |
