Size |
45 | 56 | 63 | 80 | 90 | |||
|
Displacement |
Vg |
cm³ |
44.9 | 56.6 | 63 | 79.8 | 90.5 | |
|
Nominal pressure |
pnom |
bar |
400 | 400 | 400 | 400 | 400 | |
|
Maximum pressure |
pmax |
bar |
450 | 450 | 450 | 450 | 450 | |
|
Maximum speed |
nnom 1) |
rpm |
2240 | 2000 | 2000 | 1800 | 1800 | |
|
nmax 2) |
rpm |
4250 | 3750 | 3750 | 3350 | 3350 | ||
|
Flow |
at nnom |
qV |
l/min |
191 | 212 | 236 | 267 | 303 |
|
Torque |
at pnom |
M |
Nm |
286 | 360 | 401 | 508 | 576 |
|
Rotary stiffness |
c |
kNm/rad |
4.52 | 6.83 | 8.09 | 8.96 | 9.69 | |
|
Moment of inertia for rotary group |
JTW |
kg·m² |
0.0032 | 0.0032 | 0.0032 | 0.0058 | 0.0054 | |
|
Maximum angular acceleration |
ɑ |
rad/s² |
5400 | 9000 | 11100 | 7900 | 10100 | |
|
Case volume |
V |
l |
0.6 | 0.6 | 0.6 | 0.65 | 0.65 | |
|
Weight (approx.) |
m |
kg |
17 | 17 | 17 | 23 | 23 | |
